20 FOOT DELIVERY BOX

Agricultural Machinery
Supreme International
DELIVERY BOX

The 20′ Delivery Box has a struck capacity of 903 ft³ (25.6 m³) or 1,018 ft³ (28.8 m³) with extension, and requires 300 horse power (224 kW).

Unlike any other delivery system on the market, the Supreme International Delivery Box has a revolutionary AUTO FEED FLOOR DRIVE that simplifies feeding on a new level.

With a pressure sensing floor that automatically moves based on ration type, the operator no longer has to control the floor speed. This is one less step that the feeder has to accommodate for, and instead only has to focus on opening the discharge door and controlling conveyor speed.

The End Dump option is shown in the model picture and the drawing below.

Minimum Power Requirements: 300 hp / 224 kW
Unit Capacity: Stuck Capacity: 903 ft³ / 25.6 m³, Capacity with Extension: 1,018 ft³ / 28.8 m³
Tires: N/A
Max Payload: 40,000 lbs / 18,144 kg
Dimensions: Height: 92″ / 234 cm, Height w/10″ Extension: 102″ / 259 cm, Overall Width: 124″ / 315 cm, Overall Length: 283″ / 719 cm
Drive / rpm PTO: N/A
Standard Discharge Ground Clearance: N/A
Number of Knives : N/A
Conveyor: N/A
Floor Thickness: 10 GA / 3.4 mm Stainless Steel Floor
Wall Thickness: 12GA w/ 12’’ Lower Side Wall Liner
Standards Specifications: Super Slide Plastic Bottom Liner, Easy Access Back End, Auto Feed Floor Drive” Selectable System for Each Separate Ration, 4 Pt. Scale System w/ In-Cab Scale, Mirror Mount and Weight Repeater, SS Conveyor Top Pan
