KUBOTA Reversible Plough RS7005V Series
Agricultural Machinery
KUBOTA
Reversible Ploughs
Listing Description
KUBOTA Reversible Plough RS7005V Series Reversible Ploughs
The RS7005V Series Reversible Plough is designed for large areas and light to heavy soil conditions. The standard and fully adjustable Auto-line system guarantees correct pull at all times, and single piece 200 x 200 mm box section frame is induction heat-treated, with no welding to avoid spot weaknesses. Up to 8 furrows are possible.
Product Features
The Kubota RS7005V Series is built for tougher and stony conditions and is easily adaptable to different soils and tractors. With an interbody clearance of 1000 mm, clever design, and lighter weight than competitors thanks to tougher hardened steel, the RS7005V will plough on regardless of weather or crop conditions.
Aero Profile Leg
The RS7005V uses a new aero-profile leg for better soil flow. Paired with optional centrally adjustable skimmers, this plough leg design means better performance in the field.
Hydraulics and Headstock
Hydraulic front furrow adjustment and hydraulic alignment of the frame are available, and use our Variomat system for stepwise adjustable working width from 350 to 550 mm. Coupling options include cross shaft, Cat. III and Cat. IV choices.
Robust Frame
Kubota plough frames are heat treated by induction twice, with closely monitored temperature transfer, to ensure strong and uniform steel throughout that’s as much as 3 times stronger. Our frames are robust, flexible and durable, and the lighter weight ratio improves pulling force, lift capacity, wear and tear, fuel consumption and ultimately tractor lifetime. RS7005V frames have no welds and therefore no critical fail points, and the 200 x 200 mm central beam will do up to 8 furrows.
Wide Bodies
The RS7005V Series includes 2 bodies, both good for tractors with wide tyres. The steel board (#38) is suitable for all soils, wheels up to 710 mm, easy pulling and good turning. The plastic mouldboard (#34) is good for soils with high humus content but no sharp stones. Maximum working depth is 350 mm.
Heat Treatment Technology
Kubota’s heat-treatment expertise provides steel that withstands even the toughest conditions. While other manufacturers add steel and therefore weight for strength, our robust heat-treatment technology delivers the best performance-to-weight ratio on the market, with excellent hardness and wear quality.
Auto-Reset
Kubota’s automatic non-stop Auto-Reset System is unbeatable for trouble-free ploughing. The clever multi-leaf spring system allows the plough legs to release independently and smoothly over stones and other solid objects, avoiding sudden jolts and possible damage. Once the obstruction is passed, the plough body automatically returns to the correct depth.
Heavy-Duty Springs
The RS7005V Series can be equipped with leaf springs to suit various soil types. For softer soils, the normal package with 5 leaves will do the job. By contrast, the extra heavy-duty spring package includes 8 leaves, for harder and stonier settings and extreme soil conditions. Leaves are easily fixed by one central bolt.
Rear Depth Wheel
Kubota’s RS7005V large rear wheel offers ultimate stability especially in wet conditions, by distributing weight evenly to limit sinking and soil compaction. The massive 440/80R24 radial tyre handles even the most difficult conditions.
KUBOTA Reversible Ploughs at Nicholls Machinery for all your Agricultural Machinery needs.
Showcasing the Kubota Reversible Ploughs at Nicholls Machinery in Busselton Western Australia
